$5,199.00
Specification |
Details |
|---|---|
Product Dimensions |
|
| Printer Solo Size | 35.63″ x 14.37″ x 14.03″ (905 mm x 365 mm x 356.5 mm) |
| Printer Solo Weight | 61.73 lbs (34 kg) |
| Print Width | 14″ (356 mm) |
| Maximum Print Area | 14″ x 18″ (356mm x 460mm) |
Printing Capabilities |
|
| Materials Application | All fabrics, including cotton, polyester, denim, canvas, spandex, nylon, and more |
| Print Head | Epson I1600 Dual Print Head |
| Printing Resolution | 720 x 1800 DPI |
| Minimum Ink Drop Size | 3.8 pL |
| Printing Speed | Up to 50 sq ft/hr (720×1200 DPI) |
| Printing Mode | Single Sheet-Fed |
| Printing Color | CMYK+WWWW |
Software and Maintenance |
|
| Supported Software | xTool Creative Space (Includes AI-Powered Design Generator, RIP, Auto Nesting, Printing Layout, Machine Control, and more) |
| Software Compatibility | Mac, Windows Supported |
| Calibration | AI 16MP Camera Auto Calibration |
| Maintenance | Auto Printheads Cleaning Auto Ink Stir and Circulation / WIMS (White Ink Management System) Auto Refill Printheads Moisturizer App Remote Monitoring |
General |
|
| Printer Voltage | AC 100V-120V / 220V-240V |
| Printer Frequency | 50 Hz / 60 Hz |
| Printer Power Consumption: | 350W |
| Printer Sleep Mode Power Consumption | 23.5W, approximately 0.5 kWh per day |
| Operating Temperature | 59-89°F / 15-30°C (68-89°F / 20-30°C Recommended) |
| Operating Humidity | 30%-80% RH (50%-80% RH Recommended) |
What types of printing technology does the xTool Apparel Printer use?
The xTool Apparel Printer is based on DTF (Direct-to-Film) printing technology, but we’ve enhanced its features to make it more efficient and beginner-friendly. The printer is fully integrated with a baking system, automating processes like powder application, shaking, and curing that traditional DTF printers require. With just one click, the system processes and bakes your design within 8 minutes. All you need to do is heat-press the printed film onto any fabric.
Additionally, we’ve streamlined the software, so you can manage everything—from design to printing—within one program, eliminating the need for 3–5 separate tools typically required by traditional DTF printers.
Is the printer difficult to maintain?
Not at all. The xTool Apparel Printer features fully automated lifecycle maintenance, meaning most of the time it requires no manual intervention. As long as the printer remains plugged in, it continuously monitors internal humidity and temperature to automatically trigger printhead cleaning and white ink circulation, reducing the risk of clogging.
You can also monitor key metrics via our mobile app, which provides real-time updates. If an issue arises that the printer cannot resolve on its own, the app will alert you with specific instructions to address the problem.
